MS27656T21B39P
MIL-DTL-38999 Series I Connectors were developed to meet the need of the aerospace industry. Meeting or exceeding MIL-DTL-38999 Series I requirements, the Connectors provide environmental resistance and EMI performance with quick positive coupling and %100 scoop-proofness. These Connectors meet or exceed the Mil-Spec requirements and are available in aluminum, stainless steel or hermeticity options.
0.00 ₺
0.00 ₺
Brand :
QPL
Stock Code :
MS27656T21B39P
Stock Amount :
5
pcs
| Brand | QPL |
| Connector Series | MIL-DTL-38999 Series I |
| RoHS | NO |
| Connector Shell Style | Receptacle |
| Connector Mounting Type | Square Flange |
| Connector Mating Style | Bayonet |
| Shell Material | Aluminum |
| Shell Plating | Olive Drab Cadmium |
| Shell Size and Insert Arrangement | G(21)-39 |
| Number of Contacts and Contact Size | 37 X 20 + 2 X 16 AWG |
| Contact Termination Type | Crimp |
| Contact Gender | Pin |
| Operating Temperature | -65°C // +175°C |
| Keying Rotation | N |
| Mating Cycle | 500 |
