100RN09S-6C5AP
MIL-DTL-83513 Micro-D (M83513) connector series offers proven Military spec performance and reliablitiy in rectangular and stripline micro Connectors. Terminations are avaliable in a broad range including solder cup, terminated to wire harness, vertical and right angle PCB. Plastic and metal Shell versions are available in Micro-D series, in a broad range of Shell finishes.
0.00 ₺
0.00 ₺
Brand :
AMPHENOL
Stock Code :
100RN09S6C5AP
Stock Amount :
450
pcs
| Brand | AMPHENOL |
| Connector Series | MIL-DTL-83513 Micro-D Series |
| Connector Shell Style | Receptacle |
| Connector Mounting Type | Panel Mount |
| Connector Mating Style | Screw Coupling |
| Shell Material | Aluminum |
| Shell Plating | Electroless Nickel Plating |
| Shell Size and Insert Arrangement | 09 |
| Number of Contacts and Contact Size | 9 |
| Contact Termination Type | Pre Wired |
| Contact Gender | Socket |
| Operating Temperature | -55°C // +125°C |
| Mating Cycle | 500 |
| Hardware | Jackpost |
| Wire Color | Color coded per Mil-STD-681, System 1 |
| Wire Lenght (Inches) | 72 |
| Wire Size | 24 |
| Wire Type | 19 Strd. Per NEMA-HP3 (MIL-W-16878/4) |
